Replacement Wall Ties - 100 helical ties 9 mm x 280 mm and 1 SDS insertion tool
SKU
CDT-280-100-Kit
Price excl. VAT
£210.98
Price incl. VAT
£253.18
(88 items in stock)

Twistfix 9 x 280 mm replacement wall ties offer a rapid, easy, steadfast solution to cavity wall tie problems.  They are suitable for reconnecting two masonry walls with cavity widths varying from 100 to 120 mm amid imperial brickwork or 110 to 130 mm cavities where walls have 100 mm wide metric bricks and blocks.  These remedial stainless steel brick ties are the choice of professionals for wall tie replacement.

This kit's professional SDS installation tool holds and hammer-drives the remedial ties as they screw into brick, masonry or concrete when hammered into small pilot holes using the impacting action of an SDS hammer drill.  The ties grip within an interlocking undercut, creating a helical fix connection in brick, block, stone and concrete.

Our replacement wall ties have up to 50% more stainless steel mass than alternative standard 8 mm helical ties, making them markedly stronger, and their patented precision helix guarantees unmatchable performance.  The tying system is suitable for all wall types and is UKCA and CE Mark compliant in respect of EN 845-1:2013 when used in numerous masonry materials.

The 100 tie kit is enough to re-tie 40 square meters when introduced into existing walls at the stipulated rate of 2.5 ties per square metre.

Our replacement wall ties have been independently tested for tension and compression in a variety of brick block and concrete materials for compliance with BS EN 845-1, meeting the requirement for UKCA and CE marking.

 DECLARATION OF PERFORMANCE - THOR HELICAL 9mm CD TIE
 Substrate  Compressive Strength Pilot Hole Diameter Minimum Tie Embedment Cavity Width Mean Axial Load Capacity Mean Displacement  @ 1/3 of Load
 Tension   Compression  Tension Compression

 Aircrete (AAC)

 3.5N/mm2 0mm 85mm 225mm 1490N 1500N 0.66mm 0.28mm

 Concrete Block

 7N/mm2 6mm

60mm

 150mm 2870N 2700N 0.83mm 0.46mm

 Common Brick

 30N/mm2 6mm 60mm 150mm 1940N 2680N 0.75mm 0.27mm

 Perforated Brick

 40N/mm2 5mm 60mm 150mm 1990N 2790N 0.72mm 0.57mm

 Structural  Concrete  C30

 30N/mm2 7mm 40mm 150mm 2370N 2690N 0.37mm 0.28mm
